Electron Fluoride Solution Series
Fluorocarbon cooling medium
Fluorocarbon cooling medium Description
Fluorocarbon-cooled working fluids are high-permeability, high- permeability perfluorinated liquid compounds with high dielectric constant, ideal chemical inertness, excellent thermal conductivity, and good system matching compatibility. This series of products are widely used in various temperature-controlled heat dissipation systems. This product is widely used in immersed phase liquid cooling of data center servers, and is also widely used in various stages of semiconductor manufacturing to cool and cool (such as wafer manufacturing coolers, dry Etching and tempering upper and lower electrodes for temperature control, wafer pattern preparation, exposure table, and wafer test system.
High and low temperature cooling control, etc.; high-speed train power supply inverter, lithium battery power car cooling temperature control, nuclear power, UHV power grid and military radar system, wind turbine internal heating components cooling system cooling and cooling.
Fluorocarbon cooling medium Features
Ideal chemical inertness, can be widely used in various temperature control heat dissipation occasions.
Single-phase cooling has a lower gas pressure, which can reduce the sealing requirements of the equipment and the maintenance in the later maintenance, and reduce the cost.
Non-dangerous goods or not explosion, no flash point
Electrical insulation is good, with a very high breakdown voltage greater than 50KV.
A dielectric constant below 2 does not deplete data in data center applications.
Good fluidity, low viscosity compared to clean water; good heat dissipation in temperature control systems.
Non-toxic, harmless and non-irritating
Fluorocarbon cooling medium Typical Properties
Dielectric constant
1.85
Breakdown voltage Content measurement)
48KV
Surface Tension
16.7mN/m
Boiling point
110~115°C
Density
1.812g/ml
Volume resistivity
1.4×1014
Coefficient of expansion
0.0015
Saturated water content
23.4ppm
Critical temperature
——
PH value
——
Flash point
N/A
Burning process
N/A
ODP
0
GWP
Low
Specific heat (25 ° C)
1.431J/g°C
Thermal Conductivity
0.0831
Heat of vaporization
136J/g°C
Viscosity
0.87 mPa.s
HH-705
HH-705 Description
Cooling Medium HH-705 is a highly stable fluoroether liquid with high dielectric strength, ideal chemical inertness, excellent heat transfer properties and good system compatibility. This product is widely used in various temperature control cooling systems, such as heat pipe cooling system (soaking plate, inflation plate and various types of heat pipe radiators), lithium battery power vehicles (motor, battery box, etc.) Cooling and cooling in all aspects of production and manufacturing (such as wafer manufacturing cooler, dry etching upper and lower electrode cooling temperature control, chip pattern preparation exposure machine, chip test system high and low temperature cooling control, chip sorting equipment, etc.), military Cooling and cooling of the heat dissipation system of the internal heating components of the radar system and the wind power generator.
HH-705 Features
It has good chemical inertness, it can be widely used in various temperature controlled heat dissipation applications.
Non-dangerous goods, no explosion, no flash point
Good electrical insulation, with a very high breakdown voltage greater than 40KV。
Low viscosity, good heat dissipation in the temperature control system.
Non-toxic, harmless and non-irritating
Environmentally friendly, with 0 ODP values and very low GWP value products
HH-705 Typical Properties
Name
HH-705
Dielectric constant
5.82
Dielectric strength
>40KV
Surface Tension
1.154mN/m
Boiling point
73°C
density
1.52g/ml
Specific heat capacity
137.5J/g°C
Vaporization heat
132.7J/g°C
Saturated water content
647ppm
Viscosity
0.61 CPS
PH
Not applicable
Flash point
N/A
Combustion process;
N/A
ODP
0
GWP
33
Vapor Pressure 20℃
13kpa
Fluorocarbon alkane solvent
Fluorocarbon alkane solvent Usage
Solvent: anti-fingerprint liquid and lubricant thinner
Cleaning: metal degreasing cleaning, plastic cleaning, resin cleaning, dust
removal
Heat medium: secondary refrigerant, cold load
Used to replace 3MTM NovecTM, & DupontTM Vertrel® solvents
Fluorocarbon alkane solvent Advantages
Colorless, odorless, not burning
Low surface tension, low viscosity, low latent heat of evaporation
Excellent heat resistance, chemical resistance and hydrolysis resistance
The performance is closest to CFCs and the ODP value is zero
Fluorocarbon alkane solvent Typical Properties
Boiling point
90-110℃
density
1.766（g/ml，25℃）
Viscosity
0.62（cst）
Vapor Pressure
6(KPa, 25℃)
Perfluoro-n-heptane
≈27%
Perfluoropropylcyclohexyl ether
≈6%
Perfluorobutylcyclop entyl ether
≈36%
Perfluoro-n-octane
≈23%
Perfluorocyclodecyl ether
≈1.5%
Moisture
<50ppm
Hexafluoropropylene trimer
Hexafluoropropylene trimer Usage
Solvent: lubricant diluent
Cleaning: metal degreasing cleaning, plastic cleaning, resin cleaning, dust removal
Synthetic surfactants and polymers
Heat medium: secondary refrigerant, carrying cold
Used to replace 3MTM NovecTM, & DupontTM Vertrel® solvents
Hexafluoropropylene trimer Advantages
Colorless, odorless, not burning
Low surface tension, low viscosity, low latent heat of evaporation
Excellent heat resistance, chemical resistance and hydrolysis resistance
The performance is closest to CFCs and the ODP value is zero
Hexafluoropropylene trimer Typical Properties
Boiling point
108 ℃
density
1.75 （g/ml，25℃）
Viscosity
0.68 （cst）
Vapor Pressure
5.5 （KPa，25℃）
Surface Tension
13（dyn/cm）
content
>99%
